WP7 Series · 7.47 L · China Non-Road Stage IV
Tractor Engine WP7
Models: WP7G220E476 · WP7G230E476A · WP7G230E476 · WP7G240E476A · WP7G238E476 · WP7G248E476B · WP7G248E476 · WP7G256E476B · WP7G238E476A · WP7G248E476A · WP7G256E476 · WP7G256E476A · WP7G265E476 · WP7G287E476 · WP7G303E476
For 200-300 hp wheel tractors used in wet and dry tillage, rotary tilling and seedbed preparation, mid-season cultivation and fertilising, and short-haul heavy transport
156–223 kW / 212–303 Ps
Power range (kW / Ps)
1210 N·m / 1400–1600 rpm
Max torque speed (N·m / rpm)
At a glance
As an original Weichai diesel engine supplier, we supply the WP7 built as an Inline unit, with 7.47 L displacement. Rated output spans 156–223 kW (212–303 Ps). Peak torque reaches 1210 N·m. It is supplied to meet China Non-Road Stage IV emission requirements. Typical duty is tractor service.
Product Overview
The WP7 delivers steady power output and strong adaptability, with a mature architecture guaranteeing high reliability; power covers 162-223 kW.
Product Advantages
- High reliability. Purpose-strengthened design of the block, crank-connecting rod mechanism and shaft train for agricultural duty, giving proven durability.
- Strong power. Developed specifically for agricultural duty with high output and ample torque reserve, meeting power demands across all working conditions for higher work efficiency.
- Efficient and economical. Electronically controlled high-pressure common-rail injection, a high-efficiency turbocharging system, low-friction design and high-efficiency, low-heat-rejection combustion deliver excellent fuel economy.
- Good comfort. Pilot-injection technology and high-precision meshing gear trains reduce engine vibration and noise for better comfort.
Specifications
| Power range (kW / Ps) | 156-223/212-303 |
| Max torque speed (N·m / r/min) | 1210/1400-1600 |
| Emission standard | China Non-Road Stage IV |
| Fuel | Diesel |
| Engine type | Inline |
| Number of cylinders | 6 |
| Valves | 4 |
| Displacement (L) | 7.47 |
| Aspiration | Turbocharged, intercooled |
| Vehicle application | Tractor |
| Engine dimensions (L×W×H) (mm) | 1455×729×1526 |
| Weight (G.W.) (kg) | 1000±50 |
Note: product parameters and images are for reference only and are subject to change without notice.
Model Line-up
| Model | Rated power / speed (kW / rpm) | Max torque / speed (N·m / rpm) | Displacement (L) | Emission standard | Technology route | Application | Valves | Use | Type | Aspiration |
|---|---|---|---|---|---|---|---|---|---|---|
| WP7G220E476 | 162/2200 | 970/1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G230E476A | 169/2200 | 1005/1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G230E476 | 170/2200 | 980/1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G240E476A | 176/2200 | 1005/1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G238E476 | 175/2200 | 970/1400-1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G248E476B | 182.5/2200 | 1005/1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G248E476 | 182/2200 | 965/1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G256E476B | 188/2200 | 1005/1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G238E476A | 175/2200 | 1025/1400-1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G248E476A | 182/2200 | 1015/1400-1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G256E476 | 188/2200 | 1015/1400-1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G256E476A | 188/2200 | 1080/1400-1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G265E476 | 195/2200 | 1100/1400-1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G287E476 | 208/2200 | 1210/1400-1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
| WP7G303E476 | 223/2200 | 1210/1400-1600 | 7.47 | China Non-Road Stage IV | CR + DOC + DPF + SCR + ASC | Tractor | 4 | Tractor | Inline | Turbocharged, intercooled |
Request a Quote
Send the model designation (for example WP7G220E476), the required quantity and your destination port.
Technical details
The Weichai WP7 is built on a Inline configuration with 6 cylinders and 4 valves per cylinder architecture. Displacement is 7.47 L. Intake is turbocharged, intercooled. It is offered for diesel operation. For installation planning, the unit has overall dimensions of 1455×729×1526 and a dry weight of 1000±50 kg.
Typical applications
The Weichai WP7 is specified for tractor duty. Confirmed applications include the following, and we can advise on suitability for your machine:
- Tractor
WP7 frequently asked questions
What is the power range of the Weichai WP7?
The WP7 covers 156–223 kW (212–303 Ps). Confirm the exact sub-model code before ordering, because output varies across the model line-up.
What peak torque does the WP7 deliver?
Maximum torque reaches 1210 N·m. Torque is developed from 1400-1600 r/min. This figure governs how the machine pulls away from low engine speed, so check it against your gearbox ratios and duty cycle.
Which emission standard does the WP7 meet?
This unit is offered to China Non-Road Stage IV. Tell us your destination market and we will confirm the certification route before shipment.
Is the WP7 a genuine Weichai engine?
Yes. Units are sourced through controlled supply channels to original factory specification and are supplied with export packing and documentation.
How is the WP7 shipped and how long does delivery take?
Engines are crated for export and consolidated at the port. Send your model designation, quantity and destination port for a firm quotation and lead time.
What is the configuration of the WP7?
The WP7 is built on a Inline, 6 cylinders, 7.47 L of displacement layout. Send us your machine model if you need confirmation that this layout fits your installation.
